A data file embedded in Calcpad is saved as part of a project and does not need to be saved in the relevant module as well.

However, if you enable the Data File option before sending a calcsheet to Calcpad, you can later recall the input data by double-clicking the relevant object in Calcpad. You can use the File menu of a module to save and open input data files. Click Send to Calcpad to append the results to the active project in Calcpad.Frame Analysis, you need to view the analysis results and select individual components to be included in the calcsheet. In the case of some of the larger modules, e.g. You can optionally select the Data File to have the input data saved as part of the Calcpad project. Use the Settings function to select the components to include in the calcsheet.Go to the relevant module's Calcsheets tab.You can then choose to print or send the information to Calcpad. More information:Īfter a successful analysis or design, you can group the results on the Calcsheets tab.

Pictures can also be saved as drawings in a variety of formats. However, all pictures can be zoomed by right-clicking it and using the pop-up menu.

Some pictures have visible zoom buttons, others not. Pictures can be zoomed and panned for more detail.

#CALCPAD EXCEPTION UPDATE#

If invalid input is detected, a list of errors is normally displayed.Įntered data is typically shown in pictures that interact with the table editor to automatically update with every entry in the tables. Data is normally evaluated immediately as entered. Sumo Structural Modeller and the Modeller feature in Frame Analysis that use graphical input in a CAD-like environment. Most of the data input in PROKON is done in tables. Alternatively use F11 and F12 to move forward and back between the tabs. To display a particular tab or menu, click it with the mouse.

Help menu: Access is provided to on-line Help topics and built-in Examples.

Drawings and bending schedules can be edited and printed using Padds or AutoPadds.

Drawings or Bending Schedules tab: Most design modules are capable of generating a detailed drawing or bending schedule of the designed element.

You can choose between printing or sending the information to Calcpad.

Calcsheets tab: Analysis and design results can be accumulated in a single calcsheet.

Analysis or Design tab: Selecting this tab typically starts the analysis and displays the results.

Some modules also allow specialised input trough a separate Settings button. Frame Analysis, this tab will itself contain a number of second-level tabs. In the case of some of the larger analysis modules, e.g. Input tab: All input data is entered on this tab.

#CALCPAD EXCEPTION WINDOWS#

File menu: Standard Windows commands are provided for opening and saving data files.

Similar module layoutĪll modules present you with a number of tabbed screens together with a File and Help menu: When running PROKON for the first time, you may want to first configure the design codes, sections database. By familiarising yourself with a few concepts, you should find using the PROKON suite relatively simple and intuitive. The analysis and design modules follow a similar pattern. When used in "demo mode", modules have certain capacities or features limited. If a particular module's button has the "DEMO" superimposed over it, it means that the module is not included in your license. To run a PROKON analysis or design module, click its button in the ribbon bar.
